SWM 5000 Soil Moisture Meter
- Technical Data:Housing: splash-proof, IP40
- Working temperature: 0°C to +40°C
- Display: 54 × 32 mm; 128 × 64 Pixel
- Input: 5-pin DIN socket
- Battery: 9 V battery
- Measuring time: 2 s for moisture and temperature
- Data memory: approx. 3440 measured values
- Measuring cycle: adjustable from 1 min to 24 hours
- Mobile phone operation: with the app “SWM Companion” (Android, iOS)
- Mobile phone connection: via Bluetooth 4.2 (2.4 GHz)
- Languages: German, English, Russian
- Dimensions: 83 × 180 × 55 mm
- Weight: 330 g (basic unit)
- Soil moisture measurement:
- Unit: %VWC
- Measuring range: 0 – 50%VWC
- Resolution: 0.1%
- Accuracy: ± 5% from measured value
- Measurement method: FDR
- Calibration: via software for 0%: against air 50%VWC: in water
- Temperature measurement:
- Unit: °C
- Measuring range: 0°C to +60°C
- Resolution: 0.1°C
- Accuracy: ± 0.5°C
- Measurement method: NTC
- Calibration: not necessary (sensor internally)
- Probe for manual measurement
- Dimensions: length 1000 mm; Ø 20mm; 100 mm markings for the insertion depth
- Sensor: 1 x temperatur; 1 x soil moisture; 9 cm away from the insertion tip
- Probe: stainless steel tube with handle and attachment for measuring unit
- Weight: 1.65 kg (probe with holder)
